Maxsus past egilish sezgirlik tolasi yuqori darajada o'tkazish qobiliyatini va muloqotni uzatuvchi mulkni ta'minlaydi
Ikki parallel FRP yoki po'lat simlar kabelni siqishni yaxshi siqish va optik tolasini himoya qiladi
Kamon tipidagi optik tolali kabel oddiy tuzilishga va kuchli amaliylikka ega
Romanning floti dizayni, osonlikcha chiziq va splite, o'rnatishni soddalashtiring
Tutun past, nol halogen va alangali peshdok
1.Lsith jasad
2.FRPPRP a'zosi
3.Optik tola birligi
|
Kabel modeli |
Tola samara |
Kabel hajmi (mm) |
Kabelning og'irligi (ref) (kg / km) |
Mustahkamlik chegarasi Uzoq / qisqa muddat (N) |
Qattiq qarshilik Uzoq / qisqa muddat (N / 100mm) |
Benming radiusi Dinamik / statik (mm) |
|
Gjxfh-1xn |
1 |
(2.0 ± 0.1) * (3.0 ± 0.1) |
8 |
40/80 |
500/1000 |
15/30 |
|
Gjxfh-2xn |
2 |
(2.0 ± 0.1) * (3.0 ± 0.1) |
8.5 |
40/80 |
500/1000 |
15/30 |
|
Gjxfjh-1xn |
1 |
(2.0 ± 0.1) * (3.8 ± 0.1) |
9 |
40/80 |
500/1000 |
15/30 |
|
Gxfdh-4xn |
4 (lenta) |
(2.0 ± 0,2) * (4.0 ± 0,2) |
10 |
40/80 |
500/1000 |
15/30 |
Saqlash / foydalanish harorati: -20 ↑ ~ + 60 ℃
|
Tola turi |
Ziqna |
Dan |
Samarali rejimning samarali usuli |
10 gbit / s ERNERLE HOZIR |
Minimal Bendlar radius |
|||
|
Shart |
1310 / 1550NM |
850 / 1300NM |
850 / 1300NM |
850nm |
850nm |
/ |
||
|
Oddiy qiymat |
Maksimal qiymat |
Oddiy qiymat |
Maksimal qiymat |
|||||
|
Birlik |
db / km |
db / km |
db / km |
db / km |
Mhz.km |
Mhz.km |
m |
mm |
|
G657A1 |
0.36 / 0.22 |
0,5 / 0.4 |
- |
- |
- |
- |
- |
10 |
|
G657A2 |
0.36 / 0.22 |
0,5 / 0.4 |
- |
- |
- |
- |
- |
7.5 |
|
Om3 |
- |
- |
3.0 / 1.0 |
3.5 / 1.5 |
≥1500 / 500 |
≥2000 |
≤300 |
30 |
|
Om4 |
- |
- |
3.0 / 1.0 |
3.5 / 1.5 |
O≥3500 / 500 |
≥4700 |
≤550 |
30 |
